Last month I posted a Perl script for reading data from the Temper232. Once the problem of reading data is solved, the next step is to provide logging and alerting. I’m using rrdtool for logging and generating graphs. This might be the subject of a future blog post, but today I’m writing about alerting. For alert management, I turned to Jim Trocki’s Mon.

Mon has been around for a while. It’s not fancy, but as I’m planning to deploy on a Raspberry Pi, I need a light-weight solution. The fact that Mon is written in Perl helps quite a bit, as I’m already using Perl to extract data from the Temper232. This presentation gives a good overview of Mon and what it can do. debianhelp.co.uk has a nice set of instructions for configuring Mon with Debian.

I am using Debian GNU/Linux as a platform. There is a Mon package which can be installed with the following command line (as root):

apt-get install mon

Mon’s modular architecture makes it pretty easy to add new monitors. I went ahead and wrote a monitor for the Temper232, which is pasted below. On my Debian machine I saved this script as

/usr/lib/mon/mon.d/temper.monitor

Once the file is saved, we need modify its permission settings so that it is executable by the Mon daemon. To match the permission settings of other monitor scripts, I used the following command:

chmod a+x /usr/lib/mon/mon.d/temper.monitor

Here’s the source code of the monitor script:

#!/usr/bin/perl

use Device::SerialPort;
use Getopt::Std;

getopts("dt:l:h:");

# d debug mode
# t timeout period
# h high threshold
# l low threshold

my $timeout = $opt_t || 10;
my $minTemp = $opt_l || -99;
my $maxTemp = $opt_h || 99;

my @serialports = @ARGV;
my @failed;
my $detail;

print "testing @serialports\n" if $opt_d;

foreach my $portname (@serialports){
  my $timer = $timeout;
  $port = Device::SerialPort->new($portname)||die "Couldn't open port $!\n";
  $port->user_msg(ON);
  $port->baudrate(4800);
  $port->databits(8);
  $port->parity("none");
  $port->stopbits(1);
  $port->handshake("none");
  $port->read_char_time(0);
  $port->read_const_time(1000);
  die "Couldn't open port $!\n" unless $port->write_settings;
  my $code = "\x24\x10\x05\x01\x01\x00\x32\x01\x55";
  my $count_out = $port->write($code);
  while ($timer > 0){
    # Read enough characters from port to guarantee a complete reading
    my ($count,$saw) = $port->read(10);
    if($count > 0){
      if ($saw=~m/\x24\xfe\x02(\C\C)\x55/){
        my $raw =  unpack('n*',$1);
		$raw -= 1<<16 if $raw & 1 << 15;
		my $temp = ($raw * 0.007812);
		if ($temp > $minTemp && $temp < $maxTemp){
		  print "temperature OK\n" if $opt_d;
		  $detail .= "$portname in range: $temp\n";
	    }else{
		  push @failed,$portname;
		  $detail .= "$portname out of range: $temp\n";
		  print "temperature bad\n" if $opt_d;
		}
	    print "$temp\n" if $opt_d;
	    last;
	  }
	}
	else{
	  $timer--;
	}
  }
  $code = "\x24\x11\x00\x55";
  $port->write($code);
}
print join (" ", @failed), "\n";
print $detail;

@failed == 0 ? exit 0 : exit 1;

To use this monitor, I created a “temp” hostgroup in Mon pointing to the serial device corresponding to the Temper232. In most cases this will be /dev/ttyUSB0. Mon’s a networking tool, but since the “hostname” specified in the hostgroup is the parameter passed to the monitor script, we can use this functionality to get data from a local serial port. In /etc/mon/mon.cf, my “hostgroup” section looks like this:

#
# Define groups of hosts to monitor
#
hostgroup localhost localhost

hostgroup temp /dev/ttyUSB0

I set up the following monitoring specification for the hostgroup:

watch temp
  service temperature
    description Temp monitor
    interval 1m
    monitor temper.monitor -t 10 -l 10 -h 25
    period
      numalerts 10
      alert mail.alert bob@aol.com

The entry is fairly self-explanatory except for the switches passed to the monitor.

• -t specifies a timeout value (in seconds) to wait for the serial port
• -l specifies the low temperature minimum for our range (in Celsius)
• - h specifies the high temperature maximum for our range

If the temperature reading falls outside of the acceptable range, Mon will dispatch an e-mail alert to the address specified.

One of my projects for 2012 is building a Raspberry Pi-based data collector device. Like most others, I’m still waiting for my Pi hardware. Fortunately I’ve been able to get started with a SheevaPlug that was collecting dust at Netmon. The Sheeva and the Pi share a processor architecture and both support the Debian-ARM operating system. I anticipate being able to transition to the actual Pi hardware more or less seamlessly.

I decided to start by collecting temperature data since it’s a very common data collection scenario and there are plenty of cheap sensors available.  After a bit of research I settled on the TEMPer232. The device was attractively priced and promised to be easy to work with as it contains a USB-Serial adapter compatible with the Linux ch341 driver.

The vendor’s documentation was pretty sketchy. Luckily, a guy named Silicon Owl on LiveJournal put together a nice post of his investigation into the TEMPer232. I was able to use this information to write a basic Perl script to test out my SheevaPlug temperature sensor, which I’ve pasted below. On a Debian machine you will need to install the package libdevice-serialport-perl.

The Temper232 and it's SheevaPlug host installed in Netmon's server room.

You may want to check out my newer post which shows how to expand this script to perform alerting with Mon.

#!/usr/bin/perl

use Device::SerialPort;

my $timeout = 10;
my $port = Device::SerialPort->new("/dev/ttyUSB0")||die "Couldn't open port $!\n";

$port->user_msg(ON);
$port->baudrate(4800);
$port->databits(8);
$port->parity("none");
$port->stopbits(1);
$port->handshake("none");
$port->read_char_time(0);
$port->read_const_time(1000);
die "Couldn't write port settings: $!" unless $port->write_settings;

my $code = "\x24\x10\x05\x01\x01\x00\x32\x01\x55";
my $count_out = $port->write($code);

while ($timeout > 0){
  # Read enough characters from port to guarantee a complete reading
  my ($count,$saw) = $port->read(12);
  if($count > 0){
  # Uncomment to print hex values of data from port
  #  my $output="";
  #  @data = unpack('C*',$saw);
  #  foreach my $c (@data){
  #    $output .=  sprintf("%lx",$c) . " " ;
  #  }
  #  print "$output\t";
  if ($saw=~m/\x24\xfe\x02(\C\C)\x55/){
    $raw =  unpack('n*',$1);
    $raw -= 1<<16 if $raw & 1 << 15;
    $temp = $raw * 0.007812;
    print "$temp\n";
    last;
    }
  }
  else{
    $timeout--;
  }
}
$code = "\x24\x11\x00\x55";
$port->write($code);
